Versatile series that can be manufactured as fixed glass window, louver or a combination of both
Meets Florida Building Code for High Velocity Hurricane Zone.
Large and Small missile rated
Includes intermediate horizontals (verticals depending on orientation)
Mitered cuts and assembly via fixed corner and alignment keys.
For figures and arches, corner keys and alignment keys are adjustable. Drained pockets with Hi-Flo® valves and screw covers
Glazing capabilities 7/16”, 9/16” Laminated and 1” insulated laminated
Max Dimensions as Fixed Window: 48” x 180” Design Pressures:
+85/-120 PSF
Max. Dimensions as Louvers 60” x 168” Design Pressures: +/- 80 PSF
Louvers compatible with MG 3000 door and impact rated
Powder Coating aluminum finish for superb quality and environmentally friendly operation. Meets AAMA 2604 exigencies (5 year warranty) AAMA 2605 is also available (10 year warranty)
